GDOT Automatic Insulation Oil Tester (80/100kV)






General Information

GDOT Insulation Oil Breakdown Tester is adopted industrial single plate integrated circuit, new-style I/O jack, with unique inspection and anti-interference technology to greatly improve its reliability and functionality.

Features

  • Easy operation,high automation. (only press button once and all work done automatically)
  • Menu management, data input simple and convenient.
  • Store 99 data of oil sampling tests for review and print. The test data can be saved even the power is off.
  • The clock is still on after power off. (The internal time of the system just for test reference, not for standard time)
  • Strong anti-interference, high precision testing.
  • Small measurement, light weight, convenient for outdoor operation.
  • The software can be upgraded through RS232 terminal.(Optional)


Technical parameters

    Power supply

    AC220V±10%, 50Hz

    Output voltage

    80/100 kV

    Capacity

    2.0 kVA

    Speed of voltage increase

    about 2 k V/ s

    Voltage inspection accuracy

    1 %

    Breakdown sensitivity

    < 0.1 kV

    Waveform distortion

    ≤ 1 %

    Breakdown response time

    ≤ 10 ms

    Storage environment

    Temperature: 0 ℃ -40 ℃

    Humidity: Max. relative humidity 85%

    Storage environment

    Temperature: - 20 ℃ - 60 ℃

    Humidity: Max. relative humidity 75%

    Altitude

    <1500m (if over 1500m, it can be customized)

    Dimension

    420mm*400mm*380mm(100kV)

    Weight

    45kg(N.W.) (100kV)
